ENGINE Model Kubota D902 Rated speed 2300rpm No.Of Cylinders 3 Displacement 54.8in³ Stroke 2.9in Engine Output – Net 15.8hp Bore 2.83in Warranty For Engine 2-Year or 2,000-Hour Warranty, Whichever Comes First. TRAVEL SYSTEM Track Roller Qty 6 Maximum Traction Force – Low Speed 4047lbf Type of tracks Rubber Ground Clearance 5.7in Travel Speed – High 2.67 mile/h Ground Pressure 4.2psi Travel Speed – Low 1.37 mile/h Gradeability – Maximum Maximum

ENGINE Model Vanguard 25V000 Displacement 408cc No.Of Cylinders 1 Engine Output 14hp Stroke 2.638in Warranty for Engine 3-Year Bore 3.465in Fuel Tank 1.52 gal Rated speed 3600rpm Engine Oil 0.7gal TRAVEL SYSTEM Max. Travel Speed 0.75 mile/h Ground Pressure 5.1psi Maximum Traction Force 3035 lbf Gradeability – Maximum Maximum 30 degrees Ground Clearance 15.9in Operating Weight 2370lbs HYDRAULIC SYSTEM Hydraulic Oil Tank 3.96gal Max.Discharge Flow

Standard Bucket Capacity 0.7 cu-ft Auxiliary Std Flow 5.7 gal/min Standard Bucket Width 15 in Max. Tractive Force 3035 lbf Max. Travel Speed 0.75 mile/h Arm Digging Force 1191 lbf Slewing Speed 11 rpm Bucket Digging Force 1619 lbf Max. Gradeability 30° Rated Lift Capacity 728 lb Track Ground Pressure 5.1 psi Lift Radius 80 in Hydraulic Oil Tank Capacity 3.96 gal Operating Weight 2280 lb Operating Range Max.Digging Radius On Ground 119 in Max.

Working Pressure 8-10 MPa Working Flow Rate 2.6-7.9 GPM Rate 500-1200bpm Hose Diameter 1/2 in Chisel Diameter 1.38 in Gross Weight 206 lbs Packing Size 29 x 16 x 21 in WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or

ENGINE Model Kubota D902 Rated speed 2300rpm No.Of Cylinders 3 Displacement 54.8in³ Stroke 2.9in Engine Output – Net 15.8hp Bore 2.83in Warranty For Engine 2-Year or 2,000-Hour Warranty, Whichever Comes First. TRAVEL SYSTEM Track Roller Qty 6 Maximum Traction Force – Low Speed 4047lbf Type of tracks Rubber Ground Clearance 5.7in Travel Speed – High 2.67 mile/h Ground Pressure 4.2psi Travel Speed – Low 1.37 mile/h Gradeability – Maximum Maximum

ENGINE Model Kubota D902 Rated speed 2300rpm No.of Cylinders 3 Displacement 54.8in Stroke 2.9in Engine Output – Net 15.8hp Bore 2.83in Warranty For Engine 2-Year or 2,000-Hour Warranty, Whichever Comes First. TRAVEL SYSTEM Track Roller Qty 6 Maximum Traction Force – Low Speed 4047lbf Type of tracks Rubber Ground Clearance 5.7in Travel Speed – High 2.67 mile/h Ground Pressure 4.2psi Travel Speed – Low 1.37 mile/h Gradeability – Maximum Maximum 30

ENGINE Model Kubota D722 Rated speed 2500rpm No.Of Cylinders 3 Displacement 43.88in³ Stroke 2.68in Engine Output 13.7hp Bore 2.64in Warranty for Engine 2-Year TRAVEL SYSTEM Travel Speed – High 2.24 mile/h Ground Clearance 15.9in Travel Speed – Low 1.12 mile/h Ground Pressure 5.1psi Maximum Traction Force – Low Speed 2923lbf Gradeability – Maximum Maximum 30 degrees WEIGHT Operating Weight 2700lb HYDRAULIC SYSTEM Type Load Sensing Hydraulics with

Operating Weight 1345 lb Hydraulic Oil Tank Capacity 2.64 gal Standard Bucket Capacity 0.53 ft³ Auxiliary Std Flow 4.76 gal/min Standard Bucket Width 11.4 in Max. Tractive Force 742 lbf Max. Travel Speed 1.12 mile/h Arm Digging Force 1012 lbf Slewing Speed 9.5 RPM Bucket Digging Force 1911 lbf Max. Gradeability 15° Rated Lift Capacity 330 lb Track Ground Pressure 3.84 psi Lift Radius 78.7 in Operating Range Max.Digging Radius On Ground 82.7 in
